| The GC20698-2 is Highlead`s extended twin needle long arm flatbed machine based on the GC20618-2 series. The sewing machine arm has been extended to give approximately 635mm* clearance to the right of the needles, which is around 385mm bigger than a standard arm machine. It features a triple feeding action by way of: bottom feed, needle feed and walking foot top feed and is fitted with two large vertically mounted hook & bases for use with medium to heavy weight materials. A safety clutch is fitted to help prevent damage to the hooks, bevel gears and other important parts, should the machine become jammed or over-loaded. The Highlead GC20698-2 is a long arm, twin needle, needle feed, walking foot machine, for use on medium to heavy weight materials and is aimed at job applications where a standard arm sewing machine is not suitable. - Examples:
- Large covers, upholstery panels, car trimmings, inflatable products, bouncy castles, awnings, tents, parachutes, gliders, hot air balloons, sails, lorry curtain sidings, top stitching leather etc, + many other large items..
|
| |
Features: - Extended long arm, 635mm* clearance
- 6.4mm needle gauge (optional sizes available)
- Triple feeding action
- Long stitch feature
- Large vertical axis hook & base
- Reverse stitch lever
- Hook safety clutch
- Top mounted bobbin winder
- Quiet balanced head
|  |
Specification: - Max sewing speed: 1800rpm
- Stitch length: 0-9mm
- Needle bar stroke: 36mm
- Take up stroke: 74.5mm
- Presser foot lift by hand: 8mm
- Presser foot lift by foot: 16mm
- Hook: 2x large Vertical type
- Lubrication: Manual
|
 | Options: - Electronic needle position motor (Recommended)
- Knuckle quick reverse (Recommended)
- Electronically controlled automatic thread trimmer
- Automatic air operated foot lifter unit
- Different Needle gauge set (3.2, 4.8, 8, 9.5, 12.7, 16, 19, 25.4)
|
*approximate subject to gauge size |
